Aerogel Insulation Pad for EV Lithium Battery-CA500
|
|
Values |
|
|
Hardness |
HA60±5 |
|
|
Adhesive Force of Boards |
≥10 N/25 mm |
|
|
Thermal Conductivity Coefficient |
25 C° |
≤0.03 W/ (m·k) |
|
100 C° |
≤0.035 W/ (m·k) |
|
|
500 C° |
≤0.08 W/ (m·k) |
|
|
Short-term resistance to fire |
＞1,000 C° |
|
|
Burn-through time |
＞5 min. |
|
|
Thermal Insulation Properties |
Hot-Side ＞1,000 C° Sustain 10 min. Cold-Side ＜200 C° |
|
|
Tensile Strength |
≥5 MPa |
|
|
Elongation at Break |
≥60% |
|
|
Shear Strength |
≥1 MPa |
|
|
Relaxation Rate of Compressive Stress |
≥60% |
|
|
Compression Rate of Dimensional Change |
≤2% |
|
|
Water Absorption Rate |
≤5% |
|
|
Impedance |
≥500 MΩ |
|
|
Leak Current |
≤ 1 mA |
|
|
Flame-Retardant Grade |
UJL94 V-0 |
|
|
Hazardous Substances |
RoHs Compliant |
|
|
Dimensions |
Length, width, and thickness, customizable |
|
